ML lens

/

ML (Macro Lens) are designed for high-magnification imaging, typically achieving a 1:1 magnification ratio or higher. They excel at revealing fine details of small objects, such as the hair on an insect's leg or the structure of plant cells—details that standard lenses cannot resolve due to limited magnification. Macro lenses also maintain excellent image quality and contrast at close distances, with superior control of edge distortion. In contrast, standard lenses often suffer from reduced image clarity and increased distortion when used for close-up photography.

modelRange of magnificationwork distance (mm)focal lengthdistortionchip sizeapertureinterface
ML2528F020.1X-0.4X260.4-6525<0.05%1.12.8~16C
ML3020D010.08X-0.23X400-13530<0.01% 2/32~8C
ML3528F020.25X-0.7X150-5935<0.05% 2/32.8~16C
ML5028F020.5X-0.8X132.4-95.450<0.05% 2/32.8~16C
ML7538F020.18X-0.38X471-25775<0.05% 2/32.8~16C


Customized
