120MM Telephoto lens

Parameter Overview of 120MM Telephoto Lens
/

Parameter Overview of 120MM Telephoto Lens

Sensor surface size

Diagonal: 6.9mm

focal length

24mm~120mm

resolution

330lp/mm

Interface

Customized interface

Aperture Range

F3.6~F5

Focusing Range

3m~∞

Field of view (16:9) (diagonal × horizontal × vertical), 1/2.7

15.93~3.21×13.91~2.80×7.85~1.57

back focal length (in air)

10mm

Operating method, focusing

electric

Operating method, zooming

electric

Operating method, aperture

Fixed aperture

Operating method, Auto focusing

selectable

aberration rate

1.8%~2%

Overall dimensions (Width × Height × Length)

60mm×56.5mm×100mm

Defog Function

selectable

weight

420g

operating temperature

-45℃~+70℃

TTL

110mm

Optical-Axis Consistency

No more than 3 pixels

Product Introduction


Application fields: Small and lightweight 24-120mm telephoto lens is suitable for single-person portable handheld observation or installed in the UAV pods.


Boxin's continuous zoom lenses not only have high resolution and high focus accuracy, but also possess extremely high optical axis consistency and stability. They have a wide operating temperature range and the temperature difference between the two poles can reach over 100. Boxin has a complete set of testing equipment, which not only ensures the authenticity of product performance but also enables the measurement of product reliability.

We offer customized production services for a wide range of lenses, including prime lens, two-stage zoom lenses, continuous zoom lenses, transmission type, reflection type, and non-heated infrared lenses, etc.
